產品特點 Features

◆ 模塊化可拆卸式結構設計，節省空間與清潔方便；

◆ 采用通用型PLC控製器，確保性能可靠，維護簡便；

◆ 采用先進的控製算法，自主優化，自動調校補償及震動防止功能，保證最佳的配料精度；

◆ 標準機型最多可處理四種組份(六組份以上可定製)；

◆ 彩色圖形式顯示，觸摸屏式操作，多種語言供你選擇；

◆ 具有配方存儲功能，最多可存儲100組以上配方；

◆ 分級安全密碼控製與報警曆史記錄功能；

◆ 控製器標準配置USB2.0接口，可將混料配比數據保存到U盤中，便於生產質量控製；

◆ 具備聲、光報警器，便於設備員快速準確的到達故障機器現場；

◆ 所有與原料接觸的部分都由不鏽鋼材料製成，防止原料被汙染；

◆ 可直接安裝在機器上或選配腳架安裝在機器旁(含氣動式卸料閥)。

◆ Modular and detachable structure design, saving space and convenient cleaning;

◆ Use general-purpose PLC controller to ensure reliable performance and easymaintenance;

◆ Adopt advanced control algorithm, independent optimization, automaticadjustment compensation and vibration prevention functions to ensure the bestbatching accuracy;

◆ The standard model can handle up to four components (more than sixcomponents can be customized);

◆ Color graphic display, touch screen operation, multiple languages for your choice;

◆ With formula storage function, up to 100 groups of formulas can be stored;

◆ Hierarchical security password control and alarm history record function;

◆ The controller is equipped with a standard USB2.0 interface, which can save themixing ratio data to the U disk, which is convenient for production quality control;

◆ With sound and light alarms, it is convenient for equipment personnel to quicklyand accurately reach the site of the malfunctioning machine;

◆ All parts in contact with the raw materials are made of stainless steel to preventthe raw materials from being contaminated;

◆ It can be installed directly on the machine or with optional tripods installed besidethe machine (including pneumatic discharge valve).
